Plastic mesh 100 cm green with welded wire

Quality Czech solid mesh produced under EN ISO 9001 certification !!!

The most common and most requested type of mesh for general and universal use in gardens, around houses, dia. objects, etc...

The height of the mesh is 100 cm, the mesh is 50 mm, the hot-dip galvanized wire from which the mesh is made has a diameter of 1.7 mm and including plastic coating 2.5 mm . The braided tension wire (top and bottom) has a diameter of 3.5 mm, (of which 2.5 mm has a hot-dip galvanized steel core) The mesh is sold in whole rolls of 25 m . From a height of 125 cm, we recommend also purchasing a central wire.

All wires are hot-dip galvanized and the diameter of the steel core is actually 1.7mm! . Weaker diameters, even by only tenths of a millimeter, significantly increase the softness of the mesh and reduce its lifespan and usefulness, as a weak mesh made of 1.5 or 1.65 mm wire is very susceptible to damage by dogs, vandals, garden equipment, etc.

Plastering is carried out using the extrusion method , i.e. by heat fusing and pressure pressing molten quality plastic onto hot-dip galvanized wire, which guarantees perfect adhesion and a long service life of over 20 years.

We can deliver this product to you free of charge or you can pick it up in person immediately in Vamberk , Tymákov near Pilsen or Vsetín .

The advantage of mesh with braided tension wire is that you do not have to tension the wire and the mesh separately, which speeds up the assembly process, but you need to realize that you are tensioning both the wire and the mesh in one process. When tensioning the wire, you have a whole package of mesh hanging on the tensioning wire, which has an effect on higher physical demands and also requires experience to ensure the quality of assembly. Personally, when building a fence, we prefer Extra mesh without tangled tension wire , when the assembly process can be divided into separate initial tensioning of the wires (wire warp) and then the mesh can be hung on these wires using hooks on the mesh. However, regionally (Prague, Plzeňsko), according to age-old customs, fitters are used exclusively to this type of mesh with tension wire and larger flat lengths in this design can be assembled really quickly. Installation instructions are here .

When choosing a mesh supplier, carefully compare and pay attention to the following parameters (which our quality mesh has):

The wire in the mesh is at least 1.7mm/2.5mm and made of hot-dip galvanized steel! Do not be tempted by a weaker wire - even if, for example, the stated diameter is 1.65 mm, which will actually be only 1.6 mm thanks to the tolerance of the ČSN standard. By saving a crown, you would have bought a significantly softer non-functional mesh, which will easily destroy even your dachshund.

The wire entangled in the mesh require at least a core diameter of 2.5 mm and incl. 3.5mm plastic wrap! There are also 2.2mm to 3.2mm tension wires on the market, but when heavy mesh is hung on such a weak 2.2mm/ wire, the entire fence will crack and be destroyed in the winter. Wire weaker than 3.5 mm also sags over time and creates unsightly sagging mesh waves on the fence. We even recommend tensioning wire with a diameter of 4.0 mm in combination with Forte mesh for mountainous areas.

Require mesh with 50mm mesh! With a larger mesh size (55mm, 60mm), production costs for manufacturers decrease, but the strength of the mesh is significantly reduced.

Prefer a Czech manufacturer with quality products certified by ISO 9002 systems . On the one hand, you will support the domestic labor market, and possible complaints with Polish, Slovak or Chinese manufacturers are lengthy and with an uncertain result.

Require specialized transportation and do not be satisfied with the delivery of damaged mesh by courier companies PPL, DHL, etc....! The transportation of this mesh has many pitfalls and is very demanding. The packages are bulky, difficult to tear the wire mesh, abrasion of the plastic-coated surface, damage. In 19 years of activity we know our way around this and that is why we transport everything with our own cars and experienced drivers - and for free throughout the Czech Republic within 3 working days !!!!. Everything about our transport is here.

We recommend the following for installation:

binding wire - 1 pack for 50 m of braid.
ratchets - 2 pcs for 25m mesh.
Made in the Czech Republic under EN ISO 9001 certification!!!
For orders over CZK 30,000, we will lend you a free petrol drill for drilling holes for posts.

Shipping is completely free for orders over 2,000 CZK. When ordering, we will lend you professional tools and equipment necessary for building fences for free.
Our tip!!!!! Calculate the price of your fence and all necessary components online at: kalkulator.e-pletivo.cz

Differences between mesh with and without tension wire

Mesh without tension wire only means that the mesh roll does not include tension wire. However, you do not have to worry that the fence with this mesh variant would be installed without tension wires and the mesh would not be reinforced with anything. A square mesh fence is always installed with tension wire, which is its main supporting element. Only in the case of the variant without tension wire, does it need to be purchased separately for the mesh.

→ Square mesh without pre-braided tension wire ✓

→ Square mesh with top and bottom tension wire already braided from the factory ✓

Differences in purchasing

If you are perceptive, you will have noticed that we only mentioned the upper and lower tension wires. The central tension wire is technically not possible to weave into the mesh during production. Therefore, even for the mesh variant with tension wire, the central wire needs to be purchased separately.

When is a central tension wire (hereinafter referred to as ND) needed and when is it not?

• 100 cm mesh height | not required

• 125 cm mesh height | should be

• 135 cm and higher mesh | must be

We definitely wouldn't miss the 125 cm variant and consider it for the 100 cm variant.

Price difference

As for the price, both options are about the same. The mesh without ND is a bit cheaper, but you also have to buy the aforementioned upper and lower tension wire.

Usually the difference in price is only a few crowns, at most a few dozen crowns. Therefore, if we were you, we would not make a decision based on price when choosing a variant.

The importance of the upper tension wire

In a square mesh, the upper tension wire is always the supporting element. The mesh is suspended from it. Yes, the lower and central ND are also important, but they serve more of a supporting, reinforcing element. Therefore, the upper tension wire is really the most important element of the entire fence.

Difference in assembly

We have two basic differences in assembly and two unpleasant myths associated with them.

1) Difference in working with tension wires.

2) Different ways of disconnecting and connecting the mesh.

1) Difference in assembly → different work with tension wires

Tension wire mesh (with ND)

The mesh with tension wire is installed by attaching it to the first post using tensioners (or ratchets). You unroll the mesh and then attach it to the last post and use the tensioners to turn it off.

Mesh without tension wire (without ND)

You put the mesh completely aside at the beginning of the assembly. You take a separate tension wire, install it on the posts and then turn it off. Only then do you hang the mesh on it.

Mesh installation WITHOUT entangled tension wire is faster and of higher quality. Why?

1. The upper tension wire can be switched off more efficiently because it is not loaded by the mesh.

2. Assembly is faster. Wires and mesh are easier to handle.

Moreover, you can handle the assembly by one person.

Myth:

"Installing mesh without ND takes longer because you have to hang it hook by hook."

Myth busting:

Crocheting is a quick process that anyone can do. On the other hand, installing a mesh with ND can be time-consuming, precisely because of the more difficult handling and more demanding wire cutting.

WARNING! The myth probably stems from the mistaken assumption that each joint of a non-ND mesh must be disconnected, hung and reconnected. However, this is a bad practice and, in addition to taking considerably longer to assemble, the fence will also be unstable and unsightly.

The right solution? It is always hung on only one of the two hooks. You just need to open the hook slightly and hang the mesh. Nothing comes loose! 1 hook = 2 to 4 seconds

2) Difference in assembly → method of disconnecting and connecting the mesh

The second big advantage of mesh without tension wire is that it is easier to disconnect and connect.

Since it is more demanding for mesh with ND:

A) Weave the vertical wire mesh.

B) Work with already entangled tension wire.

In case of disconnection, you must cut the tension wire. In case of connecting two rolls of mesh, you must tie it somewhere.

On the other hand, mesh without tension wire does not have these problems. You already have wires installed on the posts in the required length. Mesh without tension wire can then be easily disconnected where needed or, conversely, you can connect two rolls together and prepare the required parts for the fence.

Disconnecting and connecting is easy. To disconnect, simply unhook the hook on both ends of one vertical wire and pull the wire out. To connect two rolls, proceed in a similar manner.

Moreover, the mesh without tension wire is also visually better. There is no visible interference with the mesh anywhere on the fence.

Other minor differences

Mesh with ND

• Its upper end is quite solid and sharp.

o Potential advantage: security feature.

o Potential disadvantage: someone could get hurt.

• The role of the mesh is to make it easier to untangle "standing" vertically.

We recommend that you always unroll the mesh without tension wire on flat ground. And do so very carefully. If you pull it when you shouldn't, you risk bending the mesh wires and damaging it.

Mesh without ND

• Smaller roll dimensions.

o This makes it easier to transport. You can even fit 100 meters of mesh into a car.

o It is easier to store. This is useful if you do not start assembly immediately.

Summary

You can't go wrong with either type of mesh.

Mesh with ND

Tension wire mesh may not be a bad choice if you have a plot of land with fewer straight sides. You have enough people, patience, and you measure and think everything through well.

Mesh without ND

In most cases, as we have shown, a mesh without ND is a better option.

You will install it faster, you will be able to turn off the tension wire better and you can also handle the installation by one person. Last but not least, you will be able to easily disconnect and connect the mesh at any point.
